Nokia FWLT-C 3FE74981AA

Brand name: Nokia

Part Number: FWLT-C 3FE74981AA

Port: 16-port U-NGPON line terminal board, C version board, with flow manager.

Version: C version 7360 ISAM FX 16 port U-NGpon.

Fwlt-c is the next generation U-NGPON line terminal board.  The board can be mounted in the 7360 ISAM FX subrack.

The FWLT-C 3FE74981AA

.is a line terminating unit for the 7360 Intelligent Services Access Manager FX can be used in 7360 ISAM FX subracks

supports GPON (ITU-T G.984), XGS-PON (ITU-T G.9807.1) and Multi-PON(GPON +XGS-PON,G.9805 Amendment1) on any of the ports of the board. In addition,

it supports25GS-PON (25GS-PON MSA) on half of the ports. Multiple PON technologies can be mixed on the same board, in function of deployment needs.

contains a Traffic Manager function that provides flexible scheduling and rate limiting on a per ONT, per UNI and per class of service basis for downstream PON traffic

meets ETSI/MIl requirements

can be used in Central Office(CO) and remote deployments in7360 ISAM FX equipment

can be hot inserted or extracted

can be used in the following operational conditions:

·in a Central Office(CO) environment: 5℃ to 40C (41F to 104F) normal operating

range, or as much as -5C to 50℃ (23F to 122F)

·in a Class 2 outside plant (OSP) environment:-20℃ to 40℃ (-4F to 104F) normal

operating range, or as much as -40'C to 65C (-40F to 149°F)

.is compliant to the regulations of Restriction of the use of certain Hazardous

Substances (RoHS)and Waste Electrical and Electronic Equipment (WEEE)

is compliant to safety standardsIEC/EN 60950-1 and AS/NZS 60950-1, provided that it is installed, maintained and used according the relevant installation instructions

Note - Specific restrictions might apply for specific subrack types, fan types or optical module types.See the

7360 ISAM FX Product Information Guide for more details.

The FWLT-C CD provides support for GPON (ITU-T G.984),XGS-PON (ITU-T

G.9807.1) and Multi-PON (GPON +XGS-PON,G.9805 Amendment1) on any of the16 ports.On any of the even ports (2, 4 ... 16) it provides support for 25GS-PON(25GS-PON MSA).

Optical modules can be plugged in on the FWLT-C CD board. For an overview of the supported pluggable optical modules, see the 7360 ISAM FX Product Information Guide.

The FWLT-C CD caters for a non-blocking throughput when fully equipped with any of the supported optical modules (including the MPM modules).

The FWLT-C CD generates downstream signals synchronized to a timing reference from one of the two NT slots. All other clocks and synchronization signals are derived from on-board oscillators.

The following figures show the position of the FWLT-C  3FE74981AA
