Nokia 3HE10717CA

Brand name: Nokia

Part Number: 3HE10717CA

Board series:  7750 SR-12

Board performance:  IOM4-EB L3HQ , 200G mother blank,

description:  7750 SR-12  IOM4-EB L3HQ , 200G mother blank,

Availability: Used

Lead time-5days

Trading terms: TT

Warranty period:  180days

Country of origin:  Mexico .

The Nokia 3HE10717CA 200G motherboard card is a high-performance hardware component specifically designed for the 7750 SR series routers *, and is typically used in core,

aggregation or edge scenarios of carrier-grade networks. The following is the detailed description and application scenarios:

1. Board description

Master board card function

Model: 3HE10717CA

Capacity: Supports a total throughput of 200G and can insert 2 sub-cards (each sub-card has a maximum capacity of 100G).

Purpose: It provides high-speed data forwarding and sub-card expansion capabilities, and supports flexible business adaptation.

Compatibility: Compatible with platforms such as 7750 SR-1 and SR-7, and needs to be used in conjunction with Nokia Service Router OS (SR OS).

Sub-card type

Sub-cards are often interface modules that support multiple network interfaces, such as:

100G/40G Ethernet (QSFP28/QSFP+)

10G/25G Ethernet (SFP+/SFP28)

OTN/ Optical transmission (such as CFP2-DCO coherent optical module)

Encrypted sub-card (such as IPsec hardware acceleration)

2. Usage scenarios

a. Core/Backbone Network

High-density traffic aggregation: Used in the core network of operators to handle 200G level IP/MPLS traffic.

Large-capacity routing: Supports protocols such as BGP and IS-IS, meeting the interconnection requirements of metropolitan area networks or cross-data centers.

b. Edge/Business Access

Multi-service support: Flexibly expand interfaces through sub-cards (such as 100G high-speed uplink, 10G customer access), and be used in scenarios such as enterprise dedicated lines and mobile backhaul (IP RAN).

QoS guarantee: Supports fine-grained traffic scheduling and is suitable for low-latency services such as video transmission and cloud services.

c. Cloud/data center interconnection

High-bandwidth interconnection: Connect multiple data centers via 100G sub-cards and support overlay technologies such as EVPN and VXLAN.

Encrypted transmission: If the sub-card supports hardware encryption, it can ensure the security of cross-cloud data (such as financial and government networks).

d. 5G Mobile network

Fronthaul/midhaul: It provides high-bandwidth and low-latency backhaul capabilities for 5G base stations, and is compatible with the CU/DU separation architecture.

Network slicing: Slice isolation is achieved through SR OS to meet the SLA requirements of different 5G services.

3. Technical advantages

Flexible expansion: Master board card + sub-card design, allowing for adjustment of interface types and capacity according to business requirements.

High reliability: Supports hot plugging and redundant power supply, meeting the operator-level availability requirement of 99.999%.

Low power consumption: Advanced ASIC chips are adopted to optimize the energy consumption ratio, making it suitable for large-scale deployment.

4. Typical Configuration examples

Scene: Metropolitan area network core router

Master board card: 3HE10717CA (200G capacity)

Sub-card: 2 × 100G QSFP28 interface card (such as 3HE11271AA)

Purpose: Connect the core nodes of the metropolitan area, carry IP/MPLS traffic, and support VPN, TE tunnels, etc.

In addition to Nokia 3HE10717CA ,  Quanbo Tech supply a wide range of other Nokia 7750-SR router series . If you have any need or interest, please feel free to send inquiry to Sale@quanbotelecom.com
