Brocade 9560-16i

Manufacturer: Brocade

Part Number: 9560-16i

Profile：LP

Type ：SAS3

Number of internal ports： 2

Directly serviced SATA drives ：16

Directly serviced SAS drives ：16

Directly serviced NVMe drives 2

Raid：0, 1, 3, 5, 6, 10, 30, 50, 60

Ram GB:  8

Lifecycle: Active

Distrib. Inventory: No

Generation: 12 Gb/s

Management Software: LSI Storage Authority (LSA), StorCLI (Command-Line Interface), HII (UEFI Human Interface Infrastructure)

Cache Protection; CacheVault CVPM05

Physical Dimensions: Low profile 6.127” x 2.712”

Host Bus Type: x8 lane PCI Express 4.0

Cache Memory: 8GB

Internal Ports: 16

Data Transfer Rates: 12Gb/s SAS and 16GT/s PCIe Gen4 (NVMe) compliant

Devices Supported: SAS/SATA: 240, NVMe: 24

Internal Connectors: 2 x8 SFF-8654 (SlimSAS)

MTBF:  >3,000,000 hours at 40° C

Operating Temperature: 0°C to 55°C

OS:  Microsoft Windows, VMware vSphere/ESXi, Red Hat Enterprise Linux, SuSE Linux, Ubuntu Linux, Citrix XenServer, CentOS Linux, Debian Linux, Oracle Enterprise Linux, Fedora, FreeBSD

Regulatory Certifications: Australia/New Zealand (AS/NZS CISPR 22), Canada (ICES -003, Class B), Europe (EN55022/EN55024), Japan (VCCI V-3), Korea (RRA no 2013-24 & 25), RoHS compliant, Safety: EN/IEC/UL 60950, Taiwan (CNS 13438), USA (FCC 47 CFR part 15 Subpart B, class B), WEEE

Warranty: 1 years, free technical support, advanced replacement option at broadcom.com/support/warranty/internal-raid-hba

I/O Processor / SAS Controller: SAS3916 12Gb/s SAS Tri-Mode RAID-on-Chip (ROC)
